Cold drawn steel bar AISI 1020

Cold drawn steel bar AISI 1020, round, flat, square, hex available.

Cold Drawn Steel Bar

1.Standard
Cold Drawn Steel Bar Standards: ASTM, DIN,GB,JIS;
Steel Grade:SAE1020

2.Specifications :cold drawn;
ROUND:Dia: 3.0mm-100mm,
Length 3000-6000mm
Shape: round, flat, square, hexagonal

3.SAE 1020 chemical composition(%)

C	Si	Mn	P	S	Cr	Ni	Cu
0.18~0.23	0.15~0.35	0.30~0.60	≤0.040	≤0.050	≤0.25	≤0.25	≤0.25

4.Specification of 1020 steel

	technology	thickness/Diameter	width	length
steel round bar	forged,hot rolled,cold drawn,cold rolled,	8-100mm		5800mm
steel flat	forged,hot rolled,cold rolled,	100-200	2200	5800mm
hexagonal steel	cold drawn	8-90mm		2000-5800mm

5.Application

Cold Drawn Steel Bar 1020 Application: aviation, automo, standard parts, machine tool, agricultural machinery
